Three-phase separator and two-phase separator
за 20 дней от производителя под ключ
Проектируем, производим и устанавливаем емкостное оборудование из нержавеющих сталей (12х18Н10Т, 08х18Н10Т, AISI304, AISI321, AISI316ti и др.) по РФ и СНГ
Наши клиенты:
Наши преимущества
-
Изготовление по ГОСТ / ТУтипового и нестандартного оборудования
-
Расчет ценыи сроков в течение 1 часа
-
Цена ниже рынка на 5-7%свои проектировщики
СРО П-166-30062011 -
СМРуслуги монтажа и демонтажа
-
Сроки изготовленияот 15 дней
|
 Design equipment and development technical document Term of manufacturing from 28 days. Warranty 1 year Flexible payment system. Individual conditions of cooperation Integrated Project Management | EPC Download the brochure |
TWO PHASE SEPARATORS
Designed specifically for oil and gas. The well stream enters the separator and strikes a inlet deflector which diverts the liquid and gas downstream to the liquid section where it begins to separate.
After adequate retention time, liquid builds up in the bottom of the tank and lifts a float, through a linkage to dump the fluid.
THREE PHASE SEPARATORS
Designed specifically for oil, gas and water.
Essentially the same as a two phase except the separator has an internal inlet downcomer, which carries the fluid to the bottom of the vessel for added retention and separation time.
Both two-phase and three-phase separators can be cylindrical and spherical shapes.
Position difference:
- Vertical separators
- Vertical three-phase separator
- Vertical two-phase separator
- Horizontal separators
The vertical position of the separator ensures high efficiency and a more complete separation of gas, even at very low concentrations. A higher degree of gas saturation of oil requires horizontal separator to separate them. Such a device is relatively cheaper than vertical.
Separators packaging of carried out individually depending on the project.
Standard Features:
-
counter flange (upstream end, discharge nozzle and drain connections);
-
pressure gage/manometer.
Options:
-
autodrain
-
level bridle, made for a visual and (or) the automatic control of the current level of the liquid fraction;
-
pressure-relief valve;
-
temperature sensor;
-
heating of the separator vessels made of heating cable or hot water (steam);
-
insulation of the vessel separators with pipeline casing.
If you have a requirements specification or other product requirements information,
please send it to us via e-mail info@tpk-stella.com.
This enables our experts calculate the cost of the equipment rapidly.
We offer a comprehensive problems solutions:
Each position of the equipment is manufactured according to individual projects, to the specific requirements of the custome.
If you are in need of a Seperator contact us and let us come up with a effective solution for you!
+7 (499) 390-14-72 | zakaz.tpk-stella@mail.ru
please send it to us via e-mail info@tpk-stella.com.
This enables our experts calculate the cost of the equipment rapidly.
We offer a comprehensive problems solutions:
- design
- manufacturing
- supply
- installation
- commissioning works
- after-sales and maintenance services
Each position of the equipment is manufactured according to individual projects, to the specific requirements of the custome.
If you are in need of a Seperator contact us and let us come up with a effective solution for you!
+7 (499) 390-14-72 | zakaz.tpk-stella@mail.ru
